Chain Grate Industrial Biomass Fuel Boiler / Chamber Combustion Boiler Customized

Chain Grate Industrial Biomass Fuel Boiler / Chamber Combustion Boiler Customized

    • Chain Grate Industrial Biomass Fuel Boiler / Chamber Combustion Boiler Customized
    • Chain Grate Industrial Biomass Fuel Boiler / Chamber Combustion Boiler Customized
    • Chain Grate Industrial Biomass Fuel Boiler / Chamber Combustion Boiler Customized
    • Chain Grate Industrial Biomass Fuel Boiler / Chamber Combustion Boiler Customized
  • Chain Grate Industrial Biomass Fuel Boiler / Chamber Combustion Boiler Customized

    Thông tin chi tiết sản phẩm:

    Place of Origin: China
    Hàng hiệu: HD Boiler
    Chứng nhận: ISO9001,ASME,Grade A,SGS,EN
    Model Number: Biomass Boiler

    Thanh toán:

    Minimum Order Quantity: 1Set
    Giá bán: Negotiable
    Packaging Details: Seaworthy Packing
    Delivery Time: 30-90 Days
    Payment Terms: L/C, T/T, Western Union,
    Supply Ability: 100 Ton/Tons per Month
    Liên hệ với bây giờ
    Chi tiết sản phẩm
    Condition: New Structure: Water Tube
    Fuel: Biological Burning Style: Chamber Combustion Boiler
    Pressure: Low/High Pressure Range of Applications: Industrial
    Specification: Customized Surface Treatment: Painted
    Output: Hot Water/Steam Installation: Bulk Boiler



    Special construction technology Biomass Fuel Steam Boiler Natural circulation boiler TUV



    Product Introduction


    This boiler adopt chain grate,suitable for molding pellet fuel,can add a small amount of wood,wood block,also can burn with coal.
    This boiler adopt the newest achievements in scientific research, such as:Arched Tube plate, thread smoke tube etc, solve the tube plate crack of shell type boiler, Water wall tube burst, low efficiency, insufficient of power,Poor pf coal type adaptability etc.

    Features


    1. Durable and Long life time.
    2. Enough steam output, less heat dissipation, high thermal efficiency, lowest coal consumption.
    3. 90% min high efficiency dust collector, more Eco-friendly.
    4. Full automatic control, Protection devices for overheating, over-pressure, lacking water, leak detection, flame-out
    5. Automatic fuel feeding, automatic water feeding, automatic ash remove so on.


    Parameter



    Parameter Unit DZL1-0.7 DZL2-0.7 DZL4-1.25 DZL6-1.25 DZL8-1.6 DZL10-1.6 DZL15-1.6
    Rated steam output t/h 1 2 4 6 8 10 15
    Fixed pressure Mpa 0.7 0.7 1.25 1.25 1.6 1.6 1.6
    Fixed vapor temperature °C 170 170 194 194 204.3 204.3 204.3
    Water temperature °C 20 20 20 20 20 20 20
    Fuel   coal, biomass, straw pellet, rice husk so on
    Thermal eficiency % 80 min
    Gross weight t 13.5 18.5 23 35 46 58 83



    Advantages


    1). No need special protection when power off.
    2). Higher efficiency, heating fast.
    3). Safe and Realiable.
    4). Easy to install.
